Configuration 46
Product
Part No.
Parameter
Optional values
Default value
Analog Input, 4
Channels RTD 16
Bits with
Diagnostics 2-,
3-, or 4-Wire
EP-3704
Temperature unit
Degree Celsius (0) /
Degree Fahrenheit (1) /
Degree Kelvin (2)
Degree Celsius
Ch 0 … Ch 3 Measurement
range
PT100 -200 ... 850 °C (0)
PT200 -200 ... 850 °C (1)
PT500 -200 ... 850 °C (2)
PT1000 -200.. 850 °C (3)
NI100 -60 ... 250 °C (4) /
NI120 -80 ... 260 °C (5) /
NI200 -60 ... 250 °C (6) /
NI500 -60 ... 250 °C (7) /
NI1000 -60 ... 250 Degree (8) /
Cu10 -100 ... 260 °C (9) /
Resistance 40 Ω (10) /
Resistance 80 Ω (11) /
Resistance 150 Ω (12) /
Resistance 300 Ω (13) /
Resistance 500 Ω (14) /
Resistance 1 kΩ (15)/
Resistance 2 kΩ (16)/
Resistance 4 kΩ (17)/
disabled (18)
disabled
Ch 0 … Ch 3 Connection
type
2-wire (0) /
3-wire (1) /
4-wire (2)
2-wire
Ch 0 … Ch 3 Conversion
time
240ms (0) /
130ms (1) /
80ms (2) /
55ms (3) /
43ms (4) /
36ms (5)
80ms
Ch 0 … Ch 3 Channel
diagnostics
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3 Limit value
monitoring
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3
High limit value
-32,768 ... 32,767
0
Ch 0 … Ch 3
Low limit value
-32,768 ... 32,767
0
