Emerson PACSystems RSTi-EP

User Manual Section 3
GFK-2958L May 2021
Configuration 45
Product
Part No.
Parameter
Optional values
Default value
Analog Input, 8
Channels
Current 16 Bits
2-, 3-, or 4-Wire
EP-3368
Frequency suppression
disabled (0) /
50 Hz (1) /
60 Hz (2) /
Average over 16 values (3)
disabled
Ch 0 … Ch 3: Measurement
range
0 to 20 mA (0) /
4 to 20 mA (1) /
disabled (2)
disabled
Analog Input,
8 Channels
Current 16 Bits
2-, 3-, or 4-Wire,
Channel
Diagnostic
EP-3468
Frequency suppression
disabled (0) /
50 Hz (1) /
60 Hz (2) /
Average over 16 values (3)
disabled
K 0 ... K 7:
Channel diagnosis
disabled (0) /
enabled (1)
disabled
K 0 ... K 7: Diag short circuit
24V
disabled (0) /
enabled (1)
disabled
Ch 0 … Ch 3: Measurement
range
0 to 20 mA (0) /
4 to 20 mA (1) /
disabled (2)
disabled
Analog Input,
4 Channels
Voltage/ Current
16 Bits
2-, 3-, or 4-Wire
EP-3164
Ch 0 … Ch 3
Data format
S5 Data format (0) /
S7 Data format (1)
S7 Data format
Ch 0 … Ch 3
Output range
0 to 20 mA (0) /
4 to 20 mA (1) /
0 to 10 V (2) /
-10 to 10 V (3) /
0 to 5 V (4) /
-5 to 5 V (5) /
1 to 5 V (6) /
2 to 10 V (7) /
disabled (8)
disabled
Ch 0 … Ch 3 Substitute
value
depending on the channel data
format (S5/S7), refer to the
Tables “Value range” within
the module descriptions
0
