EPSON EPL-N4000/EPL-N4000+ Chapter 4 Disassembly and Assembly
Rev.B 135
4.2 Procedures for Disassembling
This section describes procedures for disassemblin
g
EPL-N4000/N4000+. Unless specified, assemblin
g
can be done by
reversin
g
the disassembly procedures. If you need to disassemble the
unit which are not written on the manual, refer to the exploded dia
g
rams
provided in Appendix.
Figure 4-2. Flow Chart 1
Figure 4-3. Flow Chart 2
START
Top cover
Assembly
Rear Cover
ch401
Feed, Nudger and
Retard Roll
Front Chute
Assembly
Tray 1 Feeder
Assembly
Tray 1 & Tray 2
Level Sensor
Tray 1& Tray 2 No Paper Sensor
MSI Feeder Assembly
L/H Lower Cover
Assembly
Left Lower Cover
Assembly
Left Lower Cover
Pinch Roll Assembly
Left Lower Cover
Interlock Switch
Tray 2 Take Away Senso
r
Left Chute Assembly
BTR Assembly
(Transfer Roller)
Fuser Full Cover
A
B
C
D
ch402
MSI Size Sensor
Assembly
MSI Feed Clutch
MSI No-Paper
Sensor Assembly
MSI Feed Roll
MSI Nudger Roll
MSI Nudger Roll
Assembly
MSI Pad
MSI Friction Clutch
A
