Epson EPL-N4000 - MSI Feed Clutch; Removal

EPSON EPL-N4000/EPL-N4000+ Chapter 4 Disassembly and Assembly
Rev.B 169
4.2.26 MSI Feed Clutch
(See “Upper Feeder Assembly” on pa
g
e -267)
4.2.26.1 Removal
1. Remove the MSI Tray Assembly. (“MSI Tray Assembly” on
pa
g
e -164)
2. Remove MSI Top Cover.
3. Remove the screw securin
g
the MSI Tray Support (PL4.1.9) to the
Feeder Assembly, and pull the Support away from the Assembly
(Fi
g
ure below).
Figure 4-37. Removal of MSI Tray Support
4. Disconnect the J208 runnin
g
to the MSI Feed Clutch.
5. Remove the screw securin
g
the Rear Hook Bracket to the Feeder
Assembly and remove the Bracket (Fi
g
ure below).
Figure 4-38. Removal of Rear Hook Bracket
