EPSON EPL-N4000/EPL-N4000+ CHAPTER 1 Product Description
Rev.B 20
With EPL-N4000+, MFG, MDL, DES and CID of Device ID are user-
redenfinable. The DES and CID fields don’t respond with the default
value, but respond with the defined character strin
g
only when
redefined. Device ID upon redefinition is as follows. **** is a user-
defined character strin
g
.

When Adobe PS 3 kit is not installed
MFG:****;
CMD:PJL, EJL, ESCPL2, ESCP9,PRPXL24-01,PCL,HPGL2-01,
ESCPAGE-04;
MDL:
****;
CLS:PRINTER;
DES: ****;
CID:****;

When Adobe PS 3 kit is installed
MFG:****;
CMD:PJL, EJL, ESCPL2, ESCP9,PRPXL24-01,PCL,HPGL2-01,
ESCPAGE-04;
MDL:
****;
CLS:PRINTER;
DES: ****;
CID:****;
1.3.12.2 Ethernet Interface Specification

Interface type:10BaseT, 100BaseTX, Half Duplex, Full Duplex:
Automatically switched when power is turned on.

Communication protocol

IPX/SPX(IPX, SPX, NCP, RIP, SAP, PrintServer,
RemotePrinter, NDS, SNMP,ENPC)

NetBIOS(SMB), NetBEUI

TCP/IP (IP, UDP, TCP, LPR, FTP, TELNET, ARP, ICMP,
RARP, BOOTP, DHCP, SNMP, HTTP, SNMP, ENPC)

Apple Talk (ELAP, DDP, ATP, PAP, AARP, NBP, ZIP, RTMP,
SNMP, ENPC)

ENPC (EPSON Network Peripheral Control Protocol) from EPL-
N4000+

Connector type:RJ45
Figure 1-7. RJ45 Connector/Pin Position

Appropriate cable:2-pair STP (10 BaseT, 100BaseTX)
For compliance with FCC class B, EN55022 Class B, and VCCI
ClassB, a shielded type cable must be used.
1 8
