4.2.15 Tray 1 & Tray 2 Level Sensors
(See “Tray Interface -Tray 1” on pa
e -258 and “Tray Interface-Tray 2”
on pa
e -261)
Use this procedure for removin
the Paper Level Sensors
for Trays 1 and 2.
4.2.15.1 Removal
1. Remove the Paper Tray associated with the Paper Level Sensor
you are
to remove.
2. Squeeze the Sensor latches and remove the Paper Level Sensor
from the frame.
3. Disconnect the P/J from the Sensor.
4.2.15.2 Installation
1. Reconnect the P/J to the Sensor.
2. Position the Sensor with the arms of the Sensor facin
the Feed
Assembly Actuator.
3. Reinstall the Paper Level Sensor into the slot in the frame by first
insertin
the front latch of the Sensor throu
in
the frame.
4. Press in on the rear latch and insertin
.
5. Release the rear latch and the Sensor snaps into place.
6. Release the Actuator and make sure it moves freely between the
arms of the Sensor.
7. Reconnect the P/J to the Sensor.
8. Reinstall the Paper Tray.
Figure 4-24. Removal of Level Sensor
