Epson EPL-N4000 - Left Lower Cover Interlock Switch; Removal; Installation

EPSON EPL-N4000/EPL-N4000+ Chapter 4 Disassembly and Assembly
Rev.B 182
4.2.36 Left Lower Cover Interlock Switch
(“Tray 2 Frame and Left Cover” on pa
g
e -270)
4.2.36.1 Removal
1. Open the Left Lower Cover.
2. Squeeze the sides of the Switch and pull it away from the printer
frame.
3. Disconnect J144.
Figure 4-51. Removal of Left Lower Cover Interlock Switch
4.2.36.2 Installation
1. Reconnect J144.
2. Squeeze the sides of the Switch while insertin
g
the locatin
g
tab on
the Switch into the openin
g
in the frame.
3. Release the sides of the Switch and press it into the frame.
4. The Switch snaps into place.
5. Close the Left Lower Cover.
