Safety Components

Make sure fuses, interlock switches, covers and panels are all

functionin

g

properly after you have reinstalled or replaced them.

Warning/Caution Labels

WARNING and CAUTION labels are stuck on dan

g

erous parts in the

printer to make you aware of the potential dan

g

ers that are present

when you are workin

g

with those parts.
