EPSON EPL-N4000/EPL-N4000+ Chapter 4 Disassembly and Assembly
Rev.B 148
Figure 4-18. Removal of Tray1 Take Away Roll Assembly
15. Remove the Support Assembly Sprin
g
. (“Support Assembly Sprin
g
”
on pa
g
e -152)
16. Remove Tray 1 Feed Clutch, alon
g
with the Gear and Bearin
g
.
(“Tray 1 Feed Clutch” on pa
g
e -145)
17. Remove the four screws securin
g
Tray 1 Take Away Roll Assembly
to the rear of the frame.
18. Remove the two screws securin
g
Tray 1 Take Away Roll Assembly
to the front of the frame.
19. Locate the two plastic mountin
g
pins, located at each end of the
Assembly, that secure the top of the Assembly to the bottom of the
printer frame.
20. Press the two plastic mountin
g
pins out of the mountin
g
holes, and
pull Tray 1 Take Away Assembly away from the printer.
4.2.10.2 Installation
1. Reinstall Tray 1 Take Away Roll Assembly onto the bottom of the
printer frame.
2. Ali
g
n the two plastic mountin
g
pins, located on the top of the
Assembly, with the two mountin
g
holes located in the bottom of the
printer frame.
3. Press the Assembly into the frame so the mountin
g
pins snap into
the holes.
4. Use two screws to secure the front of the Assembly to the printer
frame.
5. Use four screws to secure the rear of the Assembly to the printer
frame.
6. Reinstall Tray 1 Feed Clutch, alon
g
with the Gear and Bearin
g
.
(“Tray 1 Feed Clutch” on pa
g
e -145)
7. Reinstall the Support Assembly Sprin
g
. (“Support Assembly Sprin
g
”
on pa
g
e -152)
8. Set the printer onto Tray 2.
9. Reinstall Tray 1 Lift Motor. (“Tray 1 Lift Up Motor” on pa
g
e -144)
10. Reinstall the retainin
g
clip that is located under the Option
Connector Bracket, and use one screw to secure the clip.
CAUTION
The following steps has you lift the printer. The printer
is very heavy and requires two people to lift it. Do not
attempt to lift the printer by yourself.
