Epson EPL-N4000 - Support Assembly Spring; Removal; Installation

EPSON EPL-N4000/EPL-N4000+ Chapter 4 Disassembly and Assembly
Rev.B 152
4.2.12 Support Assembly Spring
(See “Retard and Take Away-Tray 1” on pa
g
e -260)
4.2.12.1 Removal
1. Remove Tray 1 Lift Up Motor. (“Tray 1 Lift Up Motor” on pa
g
e -144)
2. Remove the screw securin
g
the Support Assembly Sprin
g
to the
printer frame, and remove the Sprin
g
.
Figure 4-21. Removal of Support Assembly Spring
4.2.12.2 Installation
1. Reinstall the Support Assembly Sprin
g
. (Refer to the fi
g
ure for
correct positionin
g
).
2. Make sure the front and rear arms of the Sprin
g
are positioned as
shown in the fi
g
ure.
3. Use one screw to secure the Sprin
g
to the frame.
4. Reinstall Tray 1 Lift Up Motor. (“Tray 1 Lift Up Motor” on pa
g
e -144)
