Maintenance 3. Covers
146 N6 Rev.2
, and then remove the Arm #4 side covers (2 covers).
Cross recessed binding head machine screw: 14-M4×8
the Arm #4 side covers (2 covers) to the Manipulator and fix with the screws.
Cross recessed binding head machine screw: 14-M4×8
Tightening torque: 0.45 ± 0.05 N·m
Be careful not to get the cables caught in the cover.
The cover may get broken if it is
fastened too tight.
e careful not to exceed the above tightening torque.
