3.7 User Wires and Pneumatic Tubes
CAUTION
■
Only authorized or certified personnel should be allowed to perform wiring.
Wiring by unauthorized or uncertified personnel may result in bodily injury and/or
malfunction of the robot system.
User electrical wires and pneumatic tubes are contained in the cable unit.
N6-A1000**
Ether 2
Ether 1
Air 2
Air 1
One-touch fittings for ø6
mm pneumatic tube
s
User cable connector
USER
Ethernet cable connectors
N6-A
850**R
Ether 2
Ether 1
User cable connector
USER
Ethernet
cable connector
s
Air 1
Air 2
One-touch fittings for ø6 mm pneumatic tubes
