Maintenan
ce
7. Boards
N6 Rev
.2
331
7.1
Replacing the
Control Board 1
7.1.1 N6
-
A1000**
(Contr
ol Boar
d
1)
Rem
oval
(1)
T
urn OFF
the
contr
oller
.
Control Boar
d 1
(2)
Remove
the
Jo
int #
2
outsi
de cover
.
Cross rece
ssed bind
ing hea
d machine
screw
s
:
3-
M4
×8
(3)
Disconnect
the connect
or connected t
o the cont
rol
board 1.
Connector
: GS01
(4)
Remov
e the control boar
d
1.
Cross rece
ssed bind
ing hea
d machine
screw
s
:
3-
M3
×
6
342
344
