Maintenance 9. Maintenance Parts List
364 N6 Rev.2
Name Code Note
Reference in
Maintenance
Cover
(Standard
model)
Base
Base cover
1749181
Plastic cover 3
Arm #1
(N6-A1000)
Joint #1 inside cover
1739211
Joint #2 cover
1739212
Joint #1 cover
1739213
Joint #2 outside cover
1739214
Arm #1 inside cover
1739215
Arm #1
(N6-A850)
Joint #1 cover
1755217
Joint #1 inside cover
1755218
Joint #2 outside cover
1755219
Arm #1 inside cover
1755220
Arm #2
Arm #2 cover
1749176
Arm #3
Arm #3 cover
1749177
Arm #3 inside cover
1739218
Joint #4 side cover
1749178
Arm #4
Arm #4 cable cover
1739221
Arm #4 side cover
1749179
Joint #4 inside cover
1739223
Joint #4 outside cover
1749180
Cover
(Cleanroom
model)
Base
Base cover
1761617
Plastic cover
(Plating)
3
Arm #1
(N6-A1000)
Joint #1 cover
1755506
Joint #1 inside cover
1755504
Arm #1 inside cover
1755508
Joint #2 outside cover
1755507
Joint #2 cover
1755505
Arm #1
(N6-A850)
Joint #1 cover
1757779
Joint #1 inside cover
1757780
Arm #1 inside cover
1757782
Joint #2 outside cover
1757781
Arm #2
Arm #2 cover
1761612
Arm #3
Arm #3 inside cover
1755511
Arm #3 cover
1761613
Joint #4 side cover
1761614
Arm #4
Joint #4 inside cover
1755514
Joint #4 outside cover
1761616
Arm #4 side cover
1761615
Arm #4 cable cover
1739221
Pad
Arm #4
1686754
Calibration mark
1692799
8
Option
Name Code Note
Reference in
Setup & Operation
Brake release unit
(with cable and M/C short connector)
R12NZ900N4
For Europe (200V)
6.1
R12NZ900N5
For U.S. & Japan (100V)
MC short connector
R12NZ900N7
For brake release unit
Camera plate unit R12NZ9003F
Common to
C3, C4, C8, and N2
6.2
Tool adapter (ISO flange)
R12NZ900Z4
6.3
User connector kit
D-sub
R12NZ900LX
6.4
