Setup 211
String TX IP Address
Sets the destination IP address that the console will send UDPstrings to. Multiple IP addresses
can be entered, separated by either a space, comma, or semicolon. Port numbers can also be
appended to IP addresses with a colon to send UDP strings specifically to that port
(10.101.2.99:8001, for example).
A combination of UDP and ACN devices is not supported. See
String Interface
for more
specific configuration information.
String MSC TX
When enabled, this setting will cause the console to send serial strings when certain actions
happen at the console. See
Sending From User Events
.
USB Serial
The table displays all connected device names and their baud rates, parity, and stop bits.
Response Serial USB
Enables or disables local USB connection to Response MIDIand SMPTE devices. Enabled by
default.
Output
Note:
Changes to these settings may require a restart. When required, a warning
message indicating a needed restart will display.
The table displays all connected device names and their port, address, RDM, doubling, and
speed information. The following settings can be edited by selecting a cell:
Address - sets the starting address for the port
RDM - enables RDM on the port
Doubled - enables dimmer doubling on the port
Speed - sets the speed for the ports. Options are: maximum, fast, medium, and slow.
The speed may need to be adjusted for certain devices. The default speed is maximum.
Local DMXOutputs
DMXOutputs
Enables or disables DMX output from the local DMX ports. Enabled by default.
Default Output Protocol
Enables or disables DMX as a default output protocol. Enabled by default.
Output In Client Mode
When enabled, all client consoles will calculate and output DMX levels through their local
DMX ports, including DMX ports provided by Gadget / Gadget II / Programming Wing.
Disabled by default.
Local Dim Dbl Offset
This offset matches the default offset in your Sensor dimmer rack processor when configuring
dimmer doubling. The default offset is 20000.
Remotes
The Allow Remotes button is for allowing Net3 RFR, iRFR, and aRFR connections. Enabled by
default. For more information see
RFR (on page570)
.
