ETC Element 2 User Manual

32 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
Eos Ti Components
Power Button
The power button on the front of the console is used to power up or power down. A separate
hard power switch, located on the rear panel, can be used to disconnect power from the
console’s internal components.
CAUTION: It is recommended that you safely power down the console via
Displays > Power Off Device before disconnecting power from the console.
CAUTION: Power cord must be connected using an earth ground
connection.
WARNING: Before servicing your console, you must switch off the power
on the rear panel and disconnect the power cord completely.
Fuse
A fuse is included for additional protection. Fuse ratings can be found on the rear panel of
your console.
CAUTION: For continued protection against risk of fire, replace only with
same type and rating of fuse.
VORSICHT: Um weiterhin gegen Brandrisiko geschützt zu sein, ersetzen Sie
die Sicherung nur mit einer Sicherung gleichen Typs und den gleichen
Nennwerten.
ATTENTION: Pour ne pas compromettre la protection contre les risques
d’incendie, remplacer par un fusible de même type et de mêmes
caractéristiques nominales.
Internal Touchscreens
Eos Ti is designed with three internal touchscreen displays.
•
The two main touchscreens may be used to display and control show data. They may also
be used as a variety of other virtual controls and displays.
•
The encoder touchscreen offers additional touch-based controls for encoder parameters.
The touchscreen angle can be adjusted by pushing the button in the center top of the display
and moving the panel up or down.
Touchscreen brightness can be controlled via the Brightness Settings (on page219)
External Monitors
Apex consoles support up to three external Windows 7-compatible Display Port monitors.
External monitors that support Display Data Channel / Command Interface (DDC/CI) via Display
Port can be dimmed from Eos via the Brightness Settings (on page219)
Eos Ti and Gio support up to three external Windows 7-compatible Display Port or DVI
monitors.

ETC Element 2 Specifications

General

DMX Outputs	2
Touchscreen	Yes
Networking	Ethernet
Type	Lighting Control Console
Master Faders	2
Encoders	4
Ethernet Ports	2
USB Ports	4
Video Output	DisplayPort
Power Input	100-240VAC, 50/60Hz
Power Supply	Internal
Control Channels	6144
Output	Art-Net
Display	Multi-Touch LCD
Storage	Solid State Drive (SSD)
