606 Eos Apex, Eos Ti, Gio, Gio @5, Ion Xe, Ion Xe 20, and Element 2 User Manual
Example: The following fields are available for the fader targets:
Device ID – the MIDI Show Control device ID that should respond to the
message
ID (subs only) – the number of the submaster fader
Level – the specified level of the fader from 0-100% (0-127 decimal, 00-
7F hex)
Fire – represents executing a macro. The following fields are available:
Device ID – the MIDI Show Control device ID that should respond to the message
ID - the macro number to be fired
Creating a MIDI Event List and Event
Open the Show Control Display
[Displays]>[More SK]>{Show Control}
Create a new Event List and choose the Network type
<Event> [6] [/] {Type} {Network} [Enter]
Enable the list to respond to {External} sources
<Event> [6] [/] {External} [Enter]
Creating a Note On Event
Create a new event and open the MIDI String configuration screen
<Event> [1] [More SK] {MIDI String}
Select the {Note On} type
{Note On}
Select the MIDI Note value, for example, Bb (B-flat)
{A#/Bb}
Select the MIDI Note octave or leave it as Any. In this example, we’ll choose Any.
<Octave> {Any}
Select the MIDI channel
<Channel> {1}
Select the velocity
<Velocity> {127}
Optionally, select the velocity threshold so that the event will be triggered if the message is
above this level. To disable velocity threshold, leave it at zero.
<Velocity Threshold> {0}
Press {OK} to save the event
{OK}
Specify the action for the event
<Event> [1] [Macro] [1] [Enter]
