Issue 4.5 August 2005 Hand-Held Terminal (HHT) 10-9
● File from Panel. This option displays (flashing)
the HHT’s current serial port settings. If they do not
match the source device’s serial port settings, press
the NO key – see graphic overleaf.
● Node Data Function. Use this option to upload the
data relating to all nodes on the system, as follows:
node serial number, node type, node ID, number of
node inputs/outputs, software version, node status.
● File Download. This option displays (flashing) the
HHT’s current serial port settings. If they do not
match the target device’s serial port settings, press
the NO key. After downloading a file to the 3GS
controller, you should perform a cold start. This
prevents conflict between the system’s log and the
downloaded literal file – see graphic overleaf.
