DMP 128 FlexPlus • Remote Control and Configuration 137
Command ASCII command
(host to device)
Response
(device to host)
Additional description
Digital I/O
Get input status
EX5@GPIT} X5#*X5$]
Get output status
E X5@*X5%GPOT} X5^*X5&]
KEY:
X5@
=
Digital I/O Channel
1 through 2
X5#
=
Action Type
0 = No action/off
Mutes
1 = Level trigger (low mutes)
2 = Level trigger (high mutes)
3 = Edge trigger (high to low mutes, low to high unmutes)
4 = Edge trigger (high to low unmutes, low to high mutes)
5 = Toggle trigger (high to low toggles mute)
6 = Toggle trigger (low to high toggles mute)
Group Mutes
7 = Level trigger (low mutes)
8 = Level trigger (high mutes)
9 = Edge trigger (high to low mutes, low to high unmutes)
10 = Edge trigger (high to low unmutes, low to high mutes)
11 = Toggle trigger (high to low toggles mute)
12 = Toggle trigger (low to high toggles mute)
Macros
13 = Edge trigger (high to low starts macro)
14 = Edge trigger (low to high starts macro)
Presets
15 = Edge trigger (high to low recalls preset)
16 = Edge trigger (low to high recalls preset)
X5$
=
Varies according to action
type
Mutes
Input number for muting. If X5# is not specified, muting matches the
input with the corresponding I/O channel number.
Group Mutes
Group member for muting. If X5# is not specified, muting matches the
group with the corresponding I/O channel number.
Macros
Macro number. If X5# is not specified, the macro number defaults to
the corresponding I/O channel number.
Presets
Preset number. If X5# is not provided, the preset number defaults to
the corresponding I/O channel number.
NOTE: Variables shown in the table above, but not listed at the bottom of this page, are listed on the next page.
