DMP 128 FlexPlus • Web Pages 176
Line Pages
Click a Line tab for configuration options. There are three pages used for line configuration.
Registration Page
Figure 202. VoIP Line Registration Page
To register a SIP account:
1. In the User Name field (see figure 202,
1
above), enter the user name currently
assigned to the DMP 128 FlexPlus through the call server.
NOTE: “User Name” is referred to as “Line Extension” by some call servers.
2. In the Authentication User Name field (
2
), enter a name for the line (optional). In
some cases, this will be the same as the user name entered in step 1.
3. In the Authentication Password field (
3
), enter the call server registration password.
NOTE: If a password is not required by the call server, leave this field blank.
4. In the Display Name field (
4
), enter a display name for the line (optional).
5. In the Primary Proxy Name/IP field (
5
), enter the call server IP address or domain
name.
6. In the Primary Proxy Port field (
6
), enter the SIP traffic port number.
NOTE: If no port number is specified by the user, 5060 is used by default.
7. Click Apply (
7
) to commit the changes to the DMP 128 FlexPlus (click Clear to clear
all fields). Committing the changes does not initiate line registration with the call server.
8. Click Register (
8
) to initiate registration with the call server. Registration is confirmed
in the Status field next to the Register button.
NOTE: If registration is unsuccessful, refer to the logs page (see Logs Page on
page179) and contact the VoIP system administrator.
NOTES:
• To unregister a line from the call server, click Unregister (
9
).
• To clear data from a field, delete the data from the field and click Apply (
7
).
figure 192. VoIP Line Registration
