Ranger HRC™ operator´s manual – Hardware installation
112 Publ. No. TM 614 006 699 Rev B – ENGLISH (EN) – Oct 30. 2008
9.2.2.2 Junction Box conguration
With this conguration, the Junction Box is used for connections of the
JCU, Power Supply unit and monitors. The system is controlled and
powered via the System Cable, connected to the JPC2 unit.
Figure 9.7 Junction Box conguration.
1
2
3
4
5
6
7
