Ranger HRC™ operator´s manual – System operation
144 Publ. No. TM 614 006 699 Rev B – ENGLISH (EN) – Oct 30. 2008
Selecting palette
Step Action
1 Press the ENTER button to enter MENU mode.
2 Select Image… from the Setup menu and press the ENTER button.
3 Select Color scale.
4 Use the LEFT/RIGHT buttons to select IR palette, normal or inverted.
Inverting palette
Step Action
1 Press the INV button to toggle between White hot and Black hot IR palette.
11.4 Auto scanning
Auto scanning is used to automatically move the system from point to
point in a preset autoscan list.
The time that the system stays on the target, the speed with which the
system moves to next autoscan point, the focus and the îš¿eld-of-view for
each autoscan point are fully programmable. It is possible to deîš¿ne up to
32 autoscan points, in up to ve lists the currently active autoscan list +
four stored lists).
11.4.1 AUTOSCAN mode
Auto scanning is performed when the system is in AUTOSCAN mode,
provided that autoscan points have been deîš¿ned.
AUTOSCAN mode
Step Action
1 Press the SCN button to enter AUTOSCAN mode.
2 The system moves automatically between the preset autoscan points.
3 Move the joystick in any direction or press the C button to exit AUTOSCAN mode.
The functions of the Joystick Control Unit JCU) in AUTOSCAN mode are
described in section 6.2.2.
