FLIR Ranger HRC MS User Manual

Ranger HRC™ operator´s manual – Technical appendices
206 Publ. No. TM 614 006 699 Rev B – ENGLISH (EN) – Oct 30. 2008
Pin Signal name Wire type
H RS485CONSTX_A AWG 26 twisted pair
J RS485CONSTX_B AWG 26 twisted pair
K Reserved
L Reserved
M Reserved
N Reserved
P RS485TX_EN_A AWG 26 twisted pair
R RS485TX_EN_B AWG 26 twisted pair
S Video positive Coax 75 Ω
T Signal GND AWG 26
U Remote present AWG 26
V Heater on AWG 26
W 28 VDC return AWG 20
X Video negative Coax 75 Ω
Y Video GND AWG 26
Z 28 VDC AWG 20
15.5.3.3 J6 – BNC connector
Standard conguration.
15.5.3.4 J7 – BNC connector
Standard conguration.
