Ranger HRC™ operator´s manual – Basic settings
132 Publ. No. TM 614 006 699 Rev B – ENGLISH (EN) – Oct 30. 2008
10.4 Miscellaneous settings
10.4.1 Preset focus distance
The preset focus distance is the position to which the system is set when
the Focus to xed position feature is performed, see section 11.2.
Setting Preset focus distance
Step Description
1 Press the ENTER button to enter MENU mode.
2 Select Image… from the Setup menu and press the ENTER button.
3 Select Preset focus distance.
4 Use the LEFT/RIGHT navigation buttons to select the desired xed focus distance.
5 Press the ENTER button to conrm and to exit the MENU mode.
10.4.2 Slave mode
The Slave mode feature is used to activate/deactivate Slave mode. When
Slave mode is active, changes in eld-of-view will apply to both the IR
and TV camera.
Setting Slave mode On/Off
Step Description
1 Press the joystick button > 1 second toggle between Slave mode on/off. The status text
Slave mode on/off is temporarily displayed.
As an alternative to using the JCU as described above, the System Soft-
ware menu system can be used to control the Slave mode setting.
NOTE: For features with on/off alternatives, the displayed feature is the action that will
be performed if the feature is selected – not the current status. That is,
Slave mode off
means that the
Slave mode is currently ON and that it will be turned OFF if the feature is
selected.
