Fuji Electric FRENIC-Ace series - Powering on and Checking

4.3 Powering ON and Checking
4-3
TEST RUN PROCEDURE
Chap 4
4.3 Powering ON and Checking
• Be sure to mount the front cover before turning the power ON. Do not remove the cover when the inverter
power is ON.
• Do not operate switches with wet hands.
Otherwise, an electric shock could occur.
Turn the power ON and check the following points. The following is a case when no function code data is changed
from the factory defaults.
(1) Check that the LED monitor displays
(des (indicating that the destination is not set) that is blinking. See
Figure 4.3-1.
(2) Check that the inverter (built-in) cooling fans rotate.
Figure 4.3-1 Display of the LED Monitor after Power-on
