Fuji Electric FRENIC-Ace series - HHD-Mode Inverters for Heavy Duty Load

12.1 Standard Model
12-12
12.1.4 HHD-mode inverters for heavy duty load
■ Standard-model, Three-phase 200 V (230 V) class series (HHD-mode: 0.1 kW to 3.7 kW)
Item Specifications
Type (FRN_ _ _ _E2S-2) 0001 0002 0004 0006 0010 0012 0020
Nominal applied motor (kW) [HP]
(Output rating)
*1
0.1
[1/8]
0.2
[1/4]
0.4
[1/2]
0.75
[1]
1.5
[2]
2.2
[3]
3.7
[5]
Output ratings
Rated capacity (kVA) *2
0.3
[0.3]
0.6
[0.6]
1.1
[1.2]
1.9
[2.0]
3.0
[3.2]
4.2
[4.4]
6.7
[7.0]
Rated voltage (V) *3
Three-phase 200 to 240 V (with AVR function)
Rated current (A) *4
0.8 1.6 3.0 5.0 8.0 11 17.5
Overload capability 150%-1 min, 200%-0.5 s
Input power
Voltage, frequency Three-phase 200 to 240 V, 50/60 Hz
Allowable voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less) *6,
Frequency: +5 to -5%
Rated input current *7
(w/o DCR) (A)
1.1 1.8 3.1 5.3 9.5 13.2 22.2
(with DCR) (A)
0.57 0.93 1.6 3.0 5.7 8.3 14.0
Required capacity
(with DCR) (kVA) *8
0.2 0.4 0.6 1.1 2.0 2.9 4.9
Braking
Torque (%)
*9
150% 100% 70% 40%
DC braking
Braking starting frequency: 0.0 to 60.0 Hz, Braking time: 0.0 to 30.0 s,
Braking level: 0 to 100%
Braking transistor Built-in as standard
Minimum resistance value(Ω)
100 40 33
Braking resistor Separately mounted option
DC reactor (DCR) Separately mounted option
Applicable safety standards IEC/EN61800-5-1: 2007
Enclosure (IEC60529) IP20, UL open type
Cooling method Natural cooling Fan cooling
Weight / Mass (kg) [lbs]
0.5
[1.1]
0.5
[1.1]
0.6
[1.3]
0.8
[1.8]
1.5
[3.3]
1.5
[3.3]
1.8
[4.0]
Note: A box () in the above table replaces GA, GB or C depending on the model.
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 220 V (230 V).
*3 Output voltage cannot exceed the power supply voltage.
*4 Setting the carrier frequency (F26) to the following value or above requires current derating.
HHD spec. of types FRN0001E2■-2 to FRN0020E2■-2 : 8 kHz,
HHD spec. of types FRN0030E2■-2 to FRN0115E2■-2 : 10 kHz,
If reduction is necessary, for details, refer to Chapter 10, Section 10.4.2 "Guideline for selecting inverter drive
mode and capacity."
*6
67 ×
(V) voltage average phase-Three
(V) voltage Min. - (V) voltage Max.
=(%) unbalance Voltage
(IEC 61800-3)
If the unbalance ratio is 2% to 3%, use an optional AC reactor (ACR).
*7 This specification is an estimated value to be applied when the power supply capacity is 500 kVA (Inverter
capacity × 10 when the capacity exceeds 50 kVA) and the power supply with %X = 5% is connected.
*8 This specification applies when a DC reactor (DCR) is used.
*9 Average braking torque for the motor running alone. It depends on the efficiency of the motor.
