Fuji Electric FRENIC-Ace series - HND-Mode Inverters for General Load

12.2 EMC Filter Built-in Type
12-19
SPECIFICATIONS
Chap 12
12.2.3 HND-mode inverters for general load
■ Three-phase 400 V (460 V) class series
Item Specifications
Type (FRN_ _ _ _E2E-4) 0002 0004 0006 0007
*10
0012
*10
Nominal applied motor (kW) [HP]
(Output rating) *1
0.75
[1]
1.1
[1.5]
2.2
[3]
3.0
[4]
5.5
[7.5]
EMC filter
Compliant with EMC Directives. Emission: Category C2. Immunity: 2nd Env.
(EN61800-3:2004)
Weight / Mass (kg) [lbs] TBD TBD TBD TBD TBD
Item Specifications
Type (FRN_ _ _ _E2E-4) 0022 0029 0037 0044 0059 0072 0085 0105
Nominal applied motor (kW) [HP]
(Output rating) *1
7.5
[10]
11
[15]
15
[20]
18.5
[25]
22
[30]
30
[40]
37
[50]
45
[60]
EMC filter
Compliant with EMC Directives. Emission: Category C3. Immunity: 2nd Env.
(EN61800-3:2004)
Weight / Mass (kg) [lbs] 6.5 [14] 6.5 [14]
11.2 [25] 11.2 [25]
10.5 [23] 11.2 [24] 26 [57] 27 [60]
Item Specifications
Type (FRN_ _ _ _E2E-4) 0139 0168 0203 0240 0290 0361 0415 0520 0590
Nominal applied motor (kW) [HP]
(Output rating) *1
55
[75]
75
[100]
90
[125]
110
[150]
132
[200]
160
[250]
200
[300]
220
[350]
280
[450]
EMC filter
Compliant with EMC Directives. Emission: Category C3. Immunity: 2nd Env.
(EN61800-3:2004)
Weight / Mass (kg) [lbs] 31 [68] 33 [73] 40 [88] 62 [137] 63 [139] 95 [209] 96 [212] 130 [287]
140 [309]
Note: A box () in the above table replaces GA or GB depending on the model.
*1 Fuji 4-pole standard motor
*10 Types FRN0007E2■-4 and FRN0012E2■-4 are ND spec; allowable ambient temperature 40°C (+104°F)
or less. The rated output current is decreased 1% for every 1°C (1.8°F) when ambient temperature is +40°C
(+104°F) or more.
The specification other than the above items is the same as “12.1.3 HND-mode inverters for general load”.
