12.3 Common Specifications
Item Explanation Remarks
Output
Setting range
Maximum
frequency
HHD/HND/HD mode: 25 to 500 Hz variable
(under V/f control, Magnetic pole position sensorless vector control）
(Up to 200 Hz in case of under vector control with speed sensor)
ND mode: 25 to 120 Hz (under any drive control)
IMPG-VC
Base frequency 25 to 500 Hz variable (in conjunction with the maximum frequency)
Starting
frequency
0.1 to 60.0 Hz variable
(0.0 Hz under vector control with speed sensor)
IMPG-VC
Carrier frequency
Three phase 200 V class series
FRN0001E2■-2 to FRN0010E2■-2, FRN0030E2■-2 to FRN0088E2■-2:
• 0.75 to 16 kHz variable (HHD/HND spec.)
FRN0012E2■-2 to FRN0020E2■-2:
• 0.75 to 16 kHz variable (HHD spec.)
• 0.75 to 10 kHz variable (ND spec.)
FRN0115E2■-2:
• 0.75 to 16 kHz variable (HHD spec.)
• 0.75 to 10 kHz variable (HND spec.)
Three phase 400 V class series
FRN0002E2■-4 to FRN0059E2■-4:
• 0.75 to 16 kHz variable (HHD/HND/HD spec.)
• 0.75 to 10 kHz variable (ND spec.)
FRN0072E2■-4 to FRN0168E2■-4:
• 0.75 to 16 kHz variable (HHD spec.)
• 0.75 to 10 kHz variable (HND/HD spec.)
• 0.75 to 6 kHz variable (ND spec.)
FRN0203E2■-4 to FRN0590E2■-4:
• 0.75 to 10 kHz variable (HHD spec.)
• 0.75 to 6 kHz variable (HND/HD/ND spec.)
Single phase 200 V class series
FRN0001E2■-7 to FRN0011E2■-7:
• 0.75 to 16 kHz variable (HHD spec.)
Note: The carrier frequency may automatically lower depending upon the ambient
temperature or the output current to protect the inverter. (The automatic
lowering function can be disabled.)
Output frequency
accuracy (Stability)
• Analog setting: ±0.2% of maximum frequency (at 25±10°C) (77±18°F)
• Keypad setting: ±0.01% of maximum frequency (at -10 to +50°C) (14±22°F)
Frequency setting
resolution
• Analog setting: 0.05% of maximum frequency
• Keypad setting: 0.01 Hz (99.99 Hz or less), 0.1 Hz (100.0 to 500 Hz)
• Link setting: 0.005% of maximum frequency or 0.01 Hz (fixed)
Speed control range
• 1: 1500 (Minimum speed : Nominal speed, 4P, 1 to 1500 r/min)
• 1: 100 (Minimum speed : Nominal speed, 4P, 15 to 1500 r/min)
• 1: 10 (Minimum speed : Nominal speed, 6P, 180 to 1800 r/min)
IMPG-VC
IMPG-VF
PM-SVC
Speed control
accuracy
• Analog setting: ±0.2% of maximum frequency or below (at 25 ±10°C) (77±18°F)
• Digital setting: ±0.01% of maximum frequency or below
(at -10 to +50°C) (14 to 122°F)
IMPG-VC
• Analog setting: ±0.5% of base frequency or below (at 25 ±10°C) (77±18°F)
• Digital setting: ±0.5% of base frequency or below (-10 to +50°C) (14 to 122°F)
PM-SVC
Control method
• V/f control
• Vector control without speed sensor (Dynamic torque vector)
• V/f control, with slip compensation
• V/f control, with slip sensor (PG option）
• V/f Control with speed sensor (+Auto Torque Boost)(PG option)
• Vector control with speed sensor (PG option)
• Vector control without magnetic pole position sensor
VF
IM-SVC
VF with SC
IMPG-VF
IMPG-ATB
IMPG-VC
PM-SVC
