1.2 External View and Terminal Blocks
1-3
BEFORE USE
Chap 1
1.2 External View and Terminal Blocks
(1) Outside and inside views
(a) FRN0006E2S-2
(b) FRN0072E2S-4
(c) FRN0590E2S-4
Figure 1.2-1 Outside and Inside Views of Inverters
Cooling fans
Mounting base
Keypad
Front cover
Front cover
Warning plate
Main nameplate
Main circuit
terminal block
Warning label
Keypad enclosure
(can be opened)
Internal air circulation fan
Cooling fans
Main nameplate
Keypad
Front cover
Warning plate
Front cover
Control circuit terminal block
Main circuit
terminal block
Wiring guide
Front cover
mounting screw
Term cover
Keypad
Warning plate
Main nameplate
Term cover
mounting screw
Control circuit
terminal block
Wiring guide
Term cover
Main circuit
terminal block
Control circuit
terminal block
