11.19 Options for communication and operation overview
11-65
SELECTING PERIPHERAL EQUIPMENT
Chap 11
11.19.3 Terminal block type options
Table 11.19-3
Type Option Name Functions Refer
OPC-E2-RS RS485
communications
card
This card provides two RS-485 connectors for
multi-drop connection.
Section 11.24
OPC-E2-PG3 PG interface
(12/15V ) card
Speed control, position control and master- follower
operation are available mounting this card in the
inverter.
• Open collector (pull-up resistor: 2350Ω):30kHz
• Complementary (totem-pole push-pull):100kHz
• Voltage output : 12/15V
Section 11.25
OPC-E2-PG PG interface
(5V) card
Speed control, position control and master- follower
operation are available mounting this card in the
inverter.
• Open collector (pull-up resistor: 620Ω):30kHz
• Complementary (totem-pole push-pull):30kHz
• Voltage output : 5V
Section 11.26
11.19.4 Option keypad
Table 11.19-4
Type Option Name Functions Refer
TP-E1U Keypad with
USB port.
The operation keypad adopted large-sized 7 segments
LED to improve the visibility.
Allows to connect a computer directly with a commercial
USB cable (mini B) to be able to use FRENIC Loader
software. Additional converter is not required.
TP-E1U cannot be directly mounted on FRENIC-Ace. It
can be connected only through a cable.
Section 11.27
TP-A1-E2C Multi-functional
keypad
The operation keypad adopted LCD(Liquid Crystal
Display) with a back light.
The keypad corresponds to multi-languages.
TP-A1-E2C cannot be directly mounted on
FRENIC-Ace. It can be connected only through a cable.
Section 11.28
