Fuji Electric FRENIC-Ace series - Standard; EMC Filter Built-In Type (FRN0088 E2-2; FRN0059 E2-4 or Above)

13.2 Standard / EMC Filter Built-in Type
(FRN0088E2■-2/ FRN0059E2■-4 or above)
13-6
13.2 Standard / EMC Filter Built-in Type
(FRN0088E2■-2

/ FRN0059E2■-4

or above)
Figure 13.2-1
Power supply voltage Model Inverter type
Three-phase 200V
Standard model
FRN0088E2S-2
FRN0115E2S-2
EMC-filter built in type
FRN0088E2E-2
FRN0115E2E-2
Three-phase 400V
Standard model
FRN0059E2S-4
FRN0072E2S-4
EMC-filter built in type
FRN0059E2E-4
FRN0072E2E-4
A box () in the above table replaces GA, GB or C depending on the model.
(Unit: mm [inch])
