12.1 Standard Model
12-11
SPECIFICATIONS
Chap 12
■ Standard-model, Three-phase 400 V (460 V) class series (HND-mode: 55 kW to 280 kW)
Item Specifications
Type (FRN_ _ _ _E2S-4) 0139 0168 0203 0240 0290 0361 0415 0520 0590
Nominal applied motor (kW) [HP]
(Output rating)
*1
55
[75]
75
[100]
90
[125]
110
[150]
132
[200]
160
[250]
200
[300]
220
[350]
280
[450]
Output ratings
Rated capacity (kVA) *2
85
[89]
114
[120]
134
[140]
160
[167]
193
[202]
232
[242]
287
[300]
316
[331]
396
[380]
Rated voltage (V) *
3
Three-phase 380 to 480 V (with AVR function)
Rated current (A) *4 112 150 176 210 253 304 377 415 520
Overload capability 120%-1 min
Input power
Voltage, frequency
Three-phase 380
to 480 V, 50/60 Hz
Three-phase 380 to 440 V, 50 Hz
Three-phase 380 to 480 V, 60 Hz *5
Allowable voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less) *6,
Frequency: +5 to -5%
Rated input current *7
(w/o DCR) (A)
140 – – – – – – – –
(with DCR) (A) 102 138 164 201 238 286 357 390 500
Required capacity
(with DCR) (kVA) *8
71 96 114 140 165 199 248 271 347
Braking
Torque (%)
*9
7% to 12%
DC braking
Braking starting frequency: 0.0 to 60.0 Hz, Braking time: 0.0 to 30.0 s,
Braking level: 0 to 80%
Braking transistor Separately mounted option
Minimum resistance value (Ω)
Braking resistor Separately mounted option
DC reactor (DCR)
Separately
mounted
option
Must be used. Separately mounted component. Depending on the shipping
destination, not provided with the inverter package. *11
Applicable safety standards IEC/EN61800-5-1: 2007
Enclosure (IEC60529) IP00, UL open type
Cooling method Fan cooling
Weight / Mass (kg) [lbs]
30
[66]
33
[73]
40
[88]
62
[137]
63
[139]
95
[209]
96
[212]
130
[287]
140
[309]
Note: A box () in the above table replaces GA, GB or C depending on the model.
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 440 V (460 V).
*3 Output voltage cannot exceed the power supply voltage.
*4 Setting the carrier frequency (F26) to the following value or above requires current derating.
HND spec of type FRN0022E2■-4 to FRN0059E2■-4: 10 kHz,
HND spec of type FRN0072E2■-4 to FRN0168E2■-4: 6 kHz,
HND spec of type FRN0203E2■-4 to FRN0590E2■-4: 4 kHz
If reduction is necessary, for details, refer to Figure 10.4-1 in Chapter 10 “10.4.2 Guideline for selecting
inverter drive mode and capacity.”
*5 Inverters of FRN0203E2■-4 or above (400 V class series) are equipped with a power switching connector.
Use the connector depending upon the applied voltage. For details, refer to Chapter 2 “2.2.7 Switching
Connector.”
*6
67 ×
(V) voltage average phase-Three
(V) voltage Min. - (V) voltage Max.
=(%) unbalance Voltage
(IEC 61800-3)
If the unbalance ratio is 2% to 3%, use an optional AC reactor (ACR).
*7 This specification is an estimated value to be applied when the power supply capacity is 500 kVA (Inverter
capacity × 10 when the capacity exceeds 50 kVA) and the power supply with %X = 5% is connected. When
applying with motors of 75 kW (100 HP) or above, a DC reactor (DCR) should be used.
*8 This specification applies when a DC reactor (DCR) is used.
*9 Average braking torque for the motor running alone. It depends on the efficiency of the motor.
*11 Please consult your Fuji Electric sales representative.
