Fuji Electric FRENIC-Ace series - Page 214

5.2 Function Codes Table
5-44
■ 3-phase 400V class, HP rating motor (Cont.)
Motor rated
capacity
setting range (HP)
P02/A16
Magnetic
saturation
factor 1
P16/A30
Magnetic
saturation
factor 2
P17/A31
Magnetic
saturation
factor 3
P18/A32
Magnetic
saturation
factor 4
P19/A33
Magnetic
saturation
factor 5
P20/A34
Torque
current under
vector control
P55/A55
Induced
voltage factor
under vector
control
P56/A56
0.01 to 0.11 93.8 87.5 75.0 62.5 50.0 0.10 85
0.12 to 0.24 93.3 86.1 74.4 63.6 50.7 0.13 85
0.25 to 0.49 89.7 81.9 66.9 54.5 43.3 0.27 85
0.50 to 0.99 88.7 81.3 67.0 55.2 43.8 0.55 85
1.00 to 1.99 88.3 77.7 62.6 51.8 41.1 1.11 85
2.00 to 2.99 92.1 82.8 71.1 58.1 46.2 2.21 85
3.00 to 4.99 85.1 74.6 61.7 50.3 39.8 3.32 85
5.00 to 7.49 86.0 76.9 61.3 49.5 39.1 5.54 85
7.50 to 9.99 88.6 79.2 64.9 52.7 41.8 8.30 85
10.00 to 14.99 87.7 80.0 67.1 56.1 45.6 11.07 85
15.00 to 19.99 91.3 83.3 69.9 58.0 47.0 16.61 85
20.00 to 24.99 90.5 83.5 72.1 60.7 49.5 22.15 85
25.00 to 29.99 90.7 83.0 70.7 59.9 48.7 27.69 85
30.00 to 39.99 89.7 81.3 68.9 59.1 48.4 33.22 85
40.00 to 49.99 90.2 81.6 68.7 57.2 45.8 44.30 85
50.00 to 59.99 88.7 78.9 65.4 54.2 43.4 55.37 85
60.00 to 74.99 89.0 79.7 66.8 55.4 44.4 66.45 85
75.00 to 99.99 89.2 79.3 64.7 53.6 43.1 83.06 85
100.0 to 124.9 88.1 78.0 64.3 54.2 42.9 110.7 85
125.0 to 149.9 88.8 79.0 65.0 54.0 44.0 138.4 85
150.0 to 174.9 90.5 82.6 70.7 58.7 47.8 166.1 85
175.0 to 199.9 90.3 81.9 69.8 57.8 46.6 183.0 90
200.0 to 249.9 92.2 84.8 71.1 58.6 46.9 209.2 90
250.0 to 299.9 91.9 85.5 72.3 60.0 47.6 261.5 90
300.0 to 324.9 93.1 86.1 72.9 60.8 48.6 313.8 90
325.0 to 349.9 92.2 84.9 72.7 60.5 48.9 339.9 90
350.0 to 399.9 92.7 85.6 72.9 60.9 48.9 366.1 90
400.0 to 449.9 92.7 85.6 72.9 60.9 48.9 418.4 90
450.0 to 499.9 92.7 85.6 72.9 60.9 48.9 470.7 90
500.0 to 599.9 92.7 85.6 72.9 60.9 48.9 523.0 90
600.0 to 699.9 92.7 85.6 72.9 60.9 48.9 627.6 90
700.0 to 749.9 92.7 85.6 72.9 60.9 48.9 732.2 90
750.0 to 799.9 92.7 85.6 72.9 60.9 48.9 784.0 90
800.0 or above 92.7 85.6 72.9 60.9 48.9 837.0 90
