Basic Operation 65
8 Secure the optional 550 sheet feeder to the printer by tightening the two screws provided with the feeder, with a
coin or similar object.
NOTE:
• The screw hole is located in 216 mm recess from the front of the printer.
9 Insert the standard 550 sheet tray into the printer, and push until it stops.
IMPORTANT:
• Do not use excessive force on the tray. Doing so could damage the tray or inside of the printer.
10 Reconnect all cables into the rear of the printer and turn on the printer.
NOTE:
• The printer will automatically detect the attached tray but will not detect the paper type.
11 Print the System Settings page to confirm the optional 550 sheet feeder is installed correctly.
a Press the (System) button.
b Select Report / List.
c Select System Settings, and select that report or list.
d Select Print.
The System Settings page is printed.
12 Confirm Tray 2 (550 Sheet Feeder) is listed under Printer Options in the System Settings page.
If the feeder is not listed, turn off the printer, unplug the power cord, and re-install the optional 550 sheet feeder.
