"Locating the defective server" on page 43.
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
Remove the HDD fan module (2.5-inch HDD variant), see "Removing the
HDD fan module (2.5-inch HDD variant)" on page 67.
▶
Release all HDD modules and pull them out a few centimeters, see
"Removing 2.5-inch HDD/SSD modules" on page 154.
CAUTION
The HDD modules need not to be removed.
▶
If you want to remove them nevertheless, check if all HDD
modules are uniquely identified so that you can reinsert them
into their original bays.
▶
Release all dummy modules and pull them out a few centimeters, see
"Removing a 2.5-inch HDD/SSD dummy module" on page 152.
Removing a 2.5-inch HDD/PCIe backplane
The following description is valid for:
–
An HDD backplane
–
A PCIe backplane
Configurations with up to four 2.5-inch HDDs/SSDs, there is one HDD
backplane. Configurations with up to eight 2.5-inch HDDs/SSDs, there
are either two HDD backplanes or one PCIe backplane (backplane 1)
and one HDD backplane (backplane 2).
▶
If there are two backplanes, locate the defective backplane.
▶
If applicable, disconnect all cables from the backplane(s).
Hard disk drive (HDD) / solid state drive (SSD)
160 Upgrade and Maintenance Manual TX1320 M5
