â–¶
Press outside the two locking latches (1).
â–¶
Remove the HDD fan (2).
Installing the new HDD fan
A
Figure 94: Installing the HDD fan
â–¶
Insert the HDD fan in the fan cage (1) until the locking latches snap in place
(see circles).
â–¶
Ensure that the fan label is located outside (A).
Fans
TX1320 M5
Upgrade and Maintenance Manual
177
