Figure 113: Example with two PRAID EP5x0i
▶
With two installed PRAID EP5x0i, connect the HDD LED cable as shown.
▶
Connect the SAS cables to the backplane.
For the cable plan, see "Appendix B" on page
375
.
Expansion cards and backup units
200 Upgrade and Maintenance Manual TX1320 M5
