Note on BIOS settings recovery
For replacing the system board, the BIOS has an automatic restore
function for the BIOS settings. If the BIOS settings could not be restored
after replacing the system board, you must manually change the
settings.
Ensure to note down your current BIOS settings before replacing the
system board, just in case.
When the system board is replaced, the settings in the Security tab on
the BIOS setup menu are not automatically transferred, so you must
manually restore the BIOS settings.
The settings related to Security block all data writing in order to prevent
data tampering from external sources such as applications. Restoring
BIOS settings is also blocked according to this specification.
Ensure to note down your current BIOS settings before replacing the
system board.
Note on network settings recovery
When replacing the system board, network configuration settings in the
system will be lost and replaced by default values. This applies to all
static IP address and LAN teaming configurations.
Ensure to note down your current network settings before replacing the
system board.
Preliminary steps
▶
"Locating the defective server" on page 43.
▶
"Note on network settings recovery" on page 339.
▶
"Suspending BitLocker functionality" on page 71.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
Disconnect all external cables.
▶
"Getting access to the component" on page 48.
System board and components
TX1320 M5 Upgrade and Maintenance Manual 339
