Fujitsu PRIMERGY TX1320 M5 User Manual

▶
If applicable, install the RDX drive, see "Installing the RDX drive" on
page 259.
Concluding steps
▶
Connect all cables to the system board.
For the cable plan, see "Appendix B" on page 375
.
▶
Install all remaining system board components as shown in the related
sections:
▶
If applicable, iRMC microSD card, see "Installing the iRMC microSD
card" on page 313
.
▶
If applicable, M.2 SSD, see "Installing an M.2 SSD" on page 319.
▶
If applicable, Dual microSD 64 GB Enterprise, see "Installing the Dual
microSD 64GB Enterprise" on page 329.
▶
Memory modules, see "Installing a memory module" on page 224.
Ensure that you reinstall each memory module in the slot it was
located before the replacement.
▶
Expansion cards, see "Expansion cards and backup units" on page
181
.
Ensure that you reinstall each card in the slots it was located
before the replacement.
▶
Install the corresponding HDD fan module(s), see "Installing the HDD fan
module (2.5-inch HDD variant)" on page
68
or "Installing the HDD fan
module (3.5-inch HDD variant)" on page 65.
▶
"Reassembling" on page 54.
▶
Connect all external cables.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
System board and components
344 Upgrade and Maintenance Manual TX1320 M5
