Installing the new system board
â–¶
If applicable, install the TPM, see "Installing the TPM" on page 303
.
â–¶
Check the settings on the new system board, see "Onboard settings" on
page 372.
â–¶
Insert the system board by holding it at a slight angle. Slide the connectors
into the I/O panel, see Figure 228.
â–¶
Lower the system board carefully into the chassis.
â–¶
Adjust the system board. If necessary adjust the position of the system
board with a gentle twisting motion (orange circles in Figure 227 show the
centering bolts).
â–¶
Fasten the system board with the eight screws, see Figure 227.
â–¶
Remove the plastic cover from the CPU socket of the new system board.
â–¶
Remove the CPU from the defective system board, see "Removing the
CPU" on page 234.
â–¶
Confirm that the CPU model number printed on the top of the CPU fits with
the requirements.
â–¶
Install the CPU on the new system board, see "Installing the CPU" on
page 235.
â–¶
Fit the protective plastic cover onto the socket of the defective system board
which will be sent back to spares.
Returned system boards without this cover probably have to be
scrapped.
â–¶
Install the heat sink, see "Installing the standard heat sink" on page 239 or
"Installing the performance heat sink" on page
242.
â–¶
If applicable, install the power distribution board, see "Installing the new
power distribution board" on page 128.
â–¶
If applicable, install the HDD cage, see "Installing the 2.5-inch HDD cage"
on page 62.
â–¶
If applicable, install all HDD modules, see "Installing 2.5-inch HDD/SSD
modules" on page 152.
