No. Print Description
3 PWR1 PSU connector
4 ROC Connector for Dual microSD 64GB Enterprise
cable
5 USB7 Connector for Dual microSD 64GB Enterprise
6 INTRUSION Connector for intrusion cable
7 P30 PSU connector
8 PC98 Data cable connector for standard PSU
9 FAN2 SYS Connector for FAN2 inside
10 Micro SD iRMC microSD card
11 TYPE A FRONT Connector for front USB cable
12 FRONT PANEL Front panel connector
13 TYPE C FRONT Connector for front USB cable
14 SMB SYS OOB (Out-Of-Band) connector for HDD
backplanes
15 USB8 Connector for RDX USB cable
16 PWR4 Connector for HDD backplane/ODD power
cable
17 FAN CPU Connector for CPU FAN
18 SATA 0-3 SATA HDD connector
19 FAN4 SYS Connector for FAN1 inside
20 HDD LED Connector for HDD LED cable (e.g. PRAID
EP5x0i)
21 SATA ODD Connector for SATA ODD
22 M.2 SSD2 M.2 slot 2
23 M.2 SSD1 M.2 slot 1
24 TPM Connector for optional TPM
Appendix A
TX1320 M5 Upgrade and Maintenance Manual 355
