Figure 155: Inserting the 4x 3.5 HDD extension box
▶
If applicable, route the cables of the ultraslim ODD through the bay.
▶
Insert the 4x 3.5-inch HDD extension box into installation bays 1 to 3 and
carefully push in until it lines up with the front panel.
▶
Close the locking bar
, see"Closing the accessible drive locking bar" on
page 91.
