FUTABA T12K

110
<Functions of Linkage Menu>
●Select[SOUND]intheSystem menuandaccess
thesetupscreenshownbelowbypushingtheRTN
button.
Vario Melody Volume
TheVarioMelodyVolumetoadjustbythe
hardware.(stick, trim, lever, switch)
ThisisthevolumeofVarioMelodyonly.
Setting range：0(silent)～30(maximum)
Thehardwarefortheadjustmentisselectable.
Setting range
：
J1
，
J2
，
J3
，
J4
，
T1
，
T2
，
T3
，
T4
，
SA
，
SB
，
SC
，
SD
，
SE
，
SF
，
SG
，
SH
，
LS
，
LD
，
RD
，
RS
Theoperationmodeoftheadjustmenthardwareis
selectable.
ATL+ : WhentheoperationdirectionisrightordownorC.W.,
thevolumeisincreased.
ATL- : WhentheoperationdirectionisrightordownorC.W.,
thevolumeisdecreased.
SYM. : Thecenterpositionisminimumvolume.TheBothend
pointsaremaximumvolume.
VarioMelodyonly
Thehardwareis
selectable.
Themodeisselectable.
PHONEVOLUMEis
movedtopage2/2.
The vario melody outputs from the phone jack.
*The melody function plays a different electronic melody
when rising and diving.
*To take advantage of this feature, a Futaba Telemetry Sensor
(such as SBS-01A/02A, SBS-01G/02G, VARIO-F1712,
VARIO-F1672 or GPS-F1672, sold separately) must be
installed.
Thepriorityofthephoneoutputisbelow:
SpeakingAlarm>>Speakingdata>>VarioMelody
When the melody function is active, the
vario melody outputs from the phone jack.
(Highpriority) (Lowpriority)
The melody function can be turned on and off
with the specied switch.
When the melody
function is active, “on”
is displayed.
Melody function switch display. When the cursor is
moved to this option and the RTN button is pushed, the
display changes to the switch selection screen.
Vario Melody Setting
■
RANGE
ThisisthevariablerangeoftheVarioMelody.
↑ (Climb side):Whenthevariometerisgreaterthanthis
value,Variomelodyisnotvariable.
Settingrange：OFFSETvalue～ +50m/s(SBS-01/02A,SBS-01/02G)
OFFSETvalue～+50.0m/s(GPS-F1675,
VARIO-F1712)
OFFSETvalue～+300.00m/s(VARIO-F1672)
↓ (Sink side):Whenthevariometerislessthanthisvalue,
Variomelodyisnotvariable.
Settingrange：-50m/s ～ OFFSETvalue(SBS-01/02A,SBS-01/02G)
-50.0m/s～OFFSETvalue(GPS-F1675,
VARIO-F1712)
-300.00m/s～OFFSETvalue(VARIO-F1672)
■
OFFSET
Thisisthechangingpointofclimbandsink.Whenthe
variometerisgreaterthanthisvalue,VarioMelodyisclimb
type.Whenthevariometerislessthanthis value,Vario
Melodyissinktype.
Settingrange
：
RANGE↑settingvalue
～
RANGE↓setting
value
■
DEADBAND
VarioMelodyisnotoutputinthisrange.
↑ (Climb side) :Whenthevariometerislessthanthisvalue,
Variomelodyisnotoutput.
Page3/4
Currentvariometer
value
Sinksidevalueof
RANGE
ClimbsidevalueofRANGE
Thechangingpoint
ofclimbandsink
Sinksidevalueof
DEADBAND
Climbsidevalueof
DEADBAND
Climb side
(Discontinuous sounds)
Sink side
(Continuous sounds)
[The relation of Vario Melody settings]
Fixed melody Variable melody Variable melodyNot sound Fixed melody
（m/s）
OFFSET
RANGE↑ RANGE↓DEADBAND↑ DEADBAND↓
