FUTABA T12K

177
<Functions of Model Menu (Helicopter Functions)>
●Selectthefunctionname
andreturntotheModel
menubypushingthe RTN
buttonor pushingthe
HOME/EXITbutton.
<Push Dial>
RETURN
THR HOLD
This function sets the throttle cut position for
auto rotation. The throttle servo operating speed
can be adjusted. (Speed)
Note: Initially, this setting does not assign the
throttle hold switch. Prior to adjusting the
parameters for the throttle hold, we suggest
designating a throttle hold switch. To do so,
access the Condition menu within the Model
menu options.
●Servospeed
Setting method
●Hold condition switch selection
 UsetheConditionselectmenuoftheModel
menutoassigntheholdconditionswitch.
 Selectionexample:SG
●Hold position adjustment
 Movethecursortotheholdpositionitem
andpushtheRTNbuttontoswitchtothe
datainputmode.
 AdjusttheratebyscrollingthePushdial.
 Initialvalue:17%
 Adjustmentrange:0%~50%
*Hold position sets the throttle cut position. Adjust it so that
the carburetor is completely closed.
*When the RTN button is pushed for one second, the rate is
reset to the initial value.)
 PushtheRTNbuttontoendtheadjustment
andreturntothecursormode.
●Servo speed setting
 Movethecursortotheservospeeditemand
pushtheRTNbuttontoswitchtothedata
inputmode.
 AdjusttheratebyscrollingthePushdial.
 Initialvalue:0
 Adjustmentrange:0~27(maximumdelay)
*When the RTN button is pushed for one second, the rate is
reset to the initial value.)
 PushtheRTNbuttontoreturntothecursor
mode.
●Select[THRHOLD]attheModelmenu
andaccessthesetupscreenshown
belowbypushingtheRTNbutton.
●Holdpositionsetting
●Holdposition
●Currentposition
Operation precautions
Warning
When starting the engine and flying, always
set the idle up condition switch to OFF and
start the engine at idle.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Toinputdatamode
●Dataisentered
