<Functions of Model Menu (Helicopter Functions)>
●Selectthefunctionname
andreturntotheModel
menubypushingthe RTN
buttonor pushingthe
HOME/EXITbutton.
<Push Dial>
RETURN
SWASH MIX
The swash mix function is used to correct the
swash plate in the aileron (roll) direction and
elevator (cyclic pitch) corresponding to each
operation of each condition.
This function allows the independent rate
adjustments for the ailerons, elevator and pitch.
Example of use
●Asanexample,useswashmixingtocorrect
undesirablerolltendencies.
●ForaconditionwhichusesAILtoELE,setthis
functiontoON.
 Ifthefrontofthehelicopterraisesduringa
rightroll,whentheRate2sideisinputand
therightaileronisoperated,theelevator
movestothedownside.Tunebyadjusting
theRate.
 Forleftroll,adjusttotheRate1side.
Setting method
●Activate the mixing
 Whenusingthisfunction,movethecursorto
the[ACT]itemandpushtheRTNbuttonto
switchtothedatainputmode.
 SelecttheACTmodebyscrollingthePush
dial.
*The display blinks.
 PushtheRTNbuttontoactivatethemixing
andreturntothecursormode.(ONis
displayed.)
 [Switchselection]
 When[[--]]isset,theswashmixingfunctionis
alwaysactiveandoperatedbyselectingthe
condition.
 Whensettingan[ON]/[OFF]switch,move
thecursortothe[SW]itemandpushtheRTN
buttontoaccesstheselectionscreen.Set
theswitchanditsONposition.
*For a description of the switch selection method, see the
description at the back of this manual.
●Mixing rate adjustment
 Movethecursortothemixingrateitemyou
wanttocorrectandpushtheRTNbuttonto
switchtothedatainputmode.Adjustthe
rateindependentlybyscrollingthePushdial.
 Initialvalue:0%
 Adjustmentrange:-100~+100%
*When the RTN button is pushed for one second, the rate is
reset to the initial value.
 PushtheRTNbuttontoendtheadjustment
andreturntothecursormode.
●Trim mode ON/OFF setting
 Whenchangingthetrimmode,movethe
cursortothe[TRIM]itemandpushtheRTN
buttontoswitchtothedatainputmode.
 SelectON/OFFbyscrollingthePushdial.
*The display blinks.
 PushtheRTNbuttontochangethetrim
modeON/OFFandreturntothecursor
mode.
*When mixing includes master side trim, select [ON] and
when mixing does not include master trim, select [OFF].
●Select[SWASHMIX]attheModelmenu
andaccessthesetupscreenshown
belowbypushingtheRTNbutton.
(Currently selected condition name)
●Conditionselection
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
●Toinputdatamode
●Dataisentered
