Connector / Plug
Headphone plug
Plug in commercial 3.5mm headphones to listen
to telemetry data. (See telemetry section for
detailed settings.)
Trainer function connector
When you use the trainer function, connect the
optional trainer cable between the transmitters
for teacher and student.
*You can set the trainer function on the Trainer Function
screen.
S.BUS connector (S.I/F)
When setting an S.BUS servo and telemetry
sensor, connect them both here.
(Supply power by 3-way hub or 2-way cord.)
Trainer function
connector
S.BUS
connector (S.I/F)
Headphone
plug
Headphone cable
Trainer cable
3-way hub or
2-way cord
Audible telemetry data
S.BUS servo setting
Trainer system
