FUTABA T12K

162
<Model Menu (Airplane/Glider/Multirotor Functions)>
●Selectthefunctionname
and return to the Model
menu by pushing the RTN
button or pushing the
HOME/EXIT button.
<Push Dial>
RETURN
ELEVATOR
ELEVATOR 2
(AILERON 5)
(AILERON 6)
AILEVATOR
[Correspondingmodeltype]:Airplane/glider,Ailevator
(Effective only when 2 servos used at the elevators)
This function improves the performance of the roll
axis by operating the elevators as ailerons.
Ailevator is where each elevator in a standard
(conventional) or v-tail moves independently, like
ailerons on a wing. In addition to each elevator side
moving up and down together, each side moves in
opposite directions when moving as an Ailevator. On
a V-tail, this is also known as a Ruddervator, as they
can serve the same purpose. Typically, both Ailevator
and ailerons are coupled together to maximize roll
performance, especially on larger wingspan planes.
Note:SelectAilevatorastheModelTypeattheModel
Typescreen.Thischangestheoutputchannel.Check
theFunctionmenu.
(Aileronfunction)
●Whentheelevatorsareused
as ailerons, aileron travel of
the left and right elevators
can be adjusted.
(Elevatorfunction)
●Theupanddownrateofboth
elevators when the elevator stick
is moved can be individually
adjusted.
●Select[AILEVATOR]attheModelmenu
and access the setup screen shown
below by pushing the RTN button.
Setting method
● Travel adjustment
Move the cursor to the item you want to
adjust and push the RTN button to switch to
the data input mode.
 AdjusttheratebyscrollingthePushdial.
 Initialvalue:ELE:+100%,AIL:0%
 Adjustmentrange:-120~+120%
*When the RTN button is pushed for one second, the rate is
reset to the initial value.)
 PushtheRTNbuttontoreturntothecursor
mode.
*If the mixing direction is reversed, adjustments can be made
by changing the mixing rate polarity (+ or -).
*If a large value of travel is specified, when the sticks are
moved at the same time, the controls may bind or run out of
travel. Decrease the travel until no binding occurs.
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Toinputdatamode
●Dataisentered
