FUTABA T12K

140
<Model Menu (Airplane/Glider/Multirotor Functions)>
●Selectthefunctionname
and return to the Model
menu by pushing the RTN
button or pushing the
HOME/EXIT button.
<Push Dial>
RETURN
AIL 3
(Chip Aileron)
AIL 4
(Chip Aileron)
AIL1
(Main Aileron)
AIL 2
(Main Aileron)
AIL DIFF.
[Correspondingmodeltype]:Airplane/glider,2aileronsormore
The left and right aileron differential can be
adjusted independently.
For gliders, the differential rate in butterfly
mixing can be adjusted.
*The display screen is an example. The actual
screen depends on the Model Type.
Setting method
●Aileron left/right adjustment
 Movethecursortotheaileron(AIL)1~4left(or
right)settingitemandpushtheRTNbuttonto
switch to the data input mode.
 AdjusttheaileronanglesbyscrollingthePush
dialwhenthestickismovedtotheleft(or
right)end.
 Initialvalue:100%
 Adjustmentrange:0~120%
*When the RTN button is pushed for one second, the rate is
reset to the initial value.)
 PushtheRTNbuttontoendtheadjustment
and return to the cursor mode.
(Currently selected condition name)
●Select[AILDIFF.]attheModelmenu
and access the setup screen shown
below by pushing the RTN button.
[Airplane(2A+2F)]
[Glider(4A+2F)]
●Aileronleft/right
adjustment
Scrolling
●Movingcursor
●Selectingmode
●Adjustingvalue
●Tonextpage
●Toinputdatamode
●Dataisentered
