GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 8 Replacement Procedures 8-25
8-4-5 Installing the New BEP Power Supply (cont’d)
Reverse the removal procedure to install the new BEP Power Supply.
1.) Install the UPS Control Connector Panel to the back of the BEP (Figure 8-15 on page 8-22 ).
2.) Attach the motherboard power connector from the power supply to the motherboard (Figure 8-
17 on page 8-23 ). For BEP2.1, plug the purple +5Volt Standby connector into the cable coming
from the DGVIVC Tray.
3.) Attach the Power Supply to the back of the case using the 4 screws removed in Step #11 on page
22, Figure 8-16 on page 8-23 .
4.) Replace the angle bracket securing the end of the power supply. Loosely fasten the side screw
removed in Step #7 on page 21 then replaced and tighten the 2 nuts removed in Step #6 on page
21. Finally tighten the side screw.
NOTE: It is normal to get a spark when this connection is made.
5.) Attach the 5 power connectors, removed in Step #4 on page 20, to the:
-CD
-MO
-PC2IO
- HDD
- PC Bird Card (If system has option)
NOTE: All five power connectors are exactly alike. Reference the old power supply for cable routing
purposes.
6.) If necessary, neatly bundle the power cables together and ty-wrap them to the power supply as
shown in Figure 8-11 on page 8-20 .
7.) Plug the power cable in the BEP power supply.
8.) Attach the UPS Battery to the Power Supply UPS Battery Connector removed in Step #5 on page
21.
9.) Replace the BEP side cover.
10.)Install all covers removed in the process. (click here to view the cover installation video).
