P a g e | 133

UCM6100 Series User Manual

Version 1.0.18.13

Figure 75: Zero Config Sample - Global Policy

3. Go to Web GUI→Value-added Features→Zero Config→Model Templates, create a new model template

“English Support Template” for GXP2140. Add option “Language” and set it to “English”. Then select the

option “Default Model Template” to make it the default model template.

4. Go to Web GUI→Value-added Features→Zero Config→Model Templates, create another model template

“Spanish Support Template” for GXP2140. Add option “Language” and set it to “Español”.

Default Chapter4
